2VM Series Cast Iron 2/2-Way Solenoid Valve
- Direct Acting, Normally Closed
- Port Size: 1/8"–1/4"
- Fluid Temperature: -5°C to 80°C
- Operating Pressure: 0–1.0MPa
- Media: air, water, oil, gas
2VM series is a multifunctional modular solenoid valve featuring an aluminum housing with IP65 protection for a lightweight structure and environmental adaptability. Its modular structure allows a flexible combination of multiple valves through a shared air supply manifold, significantly simplifying pneumatic circuit layouts and reducing connection points and installation space.
- Compact structure with high flow capacity, fast response, and excellent sealing for low purity media
- Low-power coil design, ideal for mobile and high-frequency applications
- Standardized thread connections and modular units allow quick maintenance, replacement, or reconfiguration to reduce downtime
- Shared manifold design reduces tubing length, minimizes leakage risk, and improves reliability
This solenoid valve is suitable for systems requiring space efficiency, frequent reconfiguration, or applications with high dustproof and waterproof requirements, such as:
- Factory automation equipment
- Packaging machinery
- Industrial production lines
- Multi-station pneumatic control systems
| Category |
|
||
| Mode of operation | Direct acting | Port size | 1/8"–1/4" |
| Series | 2VM | Function | Normally closed (NC) |
| Body material | Cast iron | Wiring | Flying leads / DIN connector |
| Control method | Solenoid valve | Protection level | IP65 |
| Operating pressure | 0-1.0MPa | Mounting | Modular assembly |
| Sealing material | NBR | Recommended installation method | Horizontally |
| Fluid temperature | -5℃ to 80 ℃ | Thread options | BSP, NPT thread |
-
Automated precision machining ensures each component is manufactured to exact specifications, which will extend product lifespan.
-
Precision machining of solenoid valve provides automatic cutting with high accuracy. The 5-axis machining combined with high-precision surface polishing guarantees exceptional concentricity and response up to milliseconds.
-
Fully automatic high/low-pressure detection equipment to detect the solenoid valve’s air tightness with high accuracy.
-
Leak testing using the water immersion method to ensure zero leakage under continuous operation.
-
Each solenoid valve undergoes air outlet testing by being submerged in water to ensure zero leakage and reliable sealing.
- Strict quality control: Each valve undergoes 30 quality inspections from raw material to final product.
- Swift delivery: Fast delivery supported by a sufficient inventory of semi-finished products to meet urgent orders.
- Cost-effective valve: Optimized engineering delivers the best value for equal quality levels in the industry.
